Hybrid Solar Inverter 24V Pure Sine Wave Inverter 2400W 3KVA Solar Panel Generator Portable Wechselrichter

Product Parameter:
Input Voltage Waveform
Sinusoidal(utility or generator)
Rated Power
3000VA/2400W
Input
Output
Surge Power
6000VA
Wareform
Pure Sine Wave
Battery & AC Charger
Battery Voltage
24VDC
Float Voltage
27VDC
Overcharge Protection
30VDC
AC Charging Current
20A30A
Solar Controller
Charging CurrentPWM
50A
Max PV Array Open Circuit Voltage
80V
Max PV Power Input
1200W
Standby Power Consumption
2W
Battery Connection
Model
Typical Amperage
Battery Capacity
Wire Size
Ring Terminal
Torque value
Cable mm2
Dimensions
Dmm
Lmm
3KVA
100A
100AH
14AWG
22
64
332
23 Nm
200AH
2*8AWG
14
6.4
29.20
AC Input/Output Connection
Model
AC Breaker
Gauge
Torque value
3KVA
32A
12 AWG
1.2~1.6 Nm
PV Connection
Model
Typical Amperage
Gauge
Torque value
3KVA
50A
8 AWG
1.4~1.6 Nm
PV Module Selection
Maximum Power(Pmax)
260W
Max.PV module numbers in series
Max. Power Voltage Vmpp(V)
30.9V
1: 30.9x1=30~32
Max.Power Current Impp(A)
8.42A
PV module numbers in parallel
Open Circuit Voltage Voc(V)
37.7V
6: 50A/8.42
Short Circuit Current Isc(A)
8.89A
Total PV module numbers: 1x6=6
Maximum PV module numbers in Series : 1
PV module numbers in parallel : 6
Total PV module numbers : 1x6=6
